Production Install

This guide installs Bloodraven for production. For a short first run, use Getting Started or the Playground first.

Prerequisites

• Kubernetes 1.31 or newer. CI tests the CRD admission rules (CEL, list-map keys, status bounds) against 1.31, and the Helm chart refuses older clusters. On 1.31 and 1.32, keep the CRDValidationRatcheting feature gate on (the default; it is GA and always on from 1.33). With it off the CRDs still install, but the API server skips one creation-time check, that spec.initFromBackup.pointInTime.archiveProfileName names an entry of spec.backup.profiles; such a restore fails with RestoreBuildFailed instead.
• Helm 3.
• Nodes labelled by site as described in Placement Contract.
• A tested StorageClass for MySQL PVCs.
• external-dns and the externaldns.k8s.io/v1alpha1 DNSEndpoint CRD.
• cert-manager, if it issues the Secret that spec.tls.secretName names.
• Prometheus and Grafana if you want the shipped monitoring path.
• Object storage or PVC storage for backups.
• Dragonfly v1.38.0+ image access if you enable spec.dragonfly for cache/session co-management. After the first probe, status.dragonfly.replTakeoverSupported reports whether the running image advertises REPLTAKEOVER.

Namespace layout

Install CRDs

GitOps users should choose one owner for CRDs. Do not let both Helm and a separate CRD application race to own the same files.

Pin one release and use it for both the chart and the CRDs. The release tag carries a v prefix; the chart version does not.

BLOODRAVEN_VERSION=v1.6.0

helm upgrade --install bloodraven bloodraven/bloodraven \
  --namespace bloodraven \
  --create-namespace \
  --version "${BLOODRAVEN_VERSION#v}"

Helm installs CRDs from the chart's crds/ directory on first install. If CRDs are managed separately, apply all five from the same release tag with server-side apply:

for crd in mysqlfailovergroups mysqlbackups mysqlbackupverifications mysqldatabases mysqlstandbyclusters; do
  kubectl apply --server-side --force-conflicts \
    -f "https://raw.githubusercontent.com/ShipStream/bloodraven/${BLOODRAVEN_VERSION}/config/crd/bases/shipstream.io_${crd}.yaml"
done

Never apply CRDs from main. main can carry schema changes that no released operator understands.

Use --server-side for CRD installs and upgrades. The MysqlFailoverGroup CRD is larger than the 256 KiB limit on the kubectl.kubernetes.io/last-applied-configuration annotation that client-side kubectl apply writes, so a plain kubectl apply -f fails with metadata.annotations: Too long: may not be more than 262144 bytes.

Then install the operator chart after the platform CRD app has applied the CRDs. Helm does not upgrade CRDs in crds/; apply CRD updates explicitly during upgrades.

Helm values

Application deployment coordination is opt-in. See the Deployment API values for auxiliary.deployAPI.enabled, the required existing escrow TLS Secret, audience, and optional NetworkPolicy. Apply the matching CRD updates before declaring MysqlDatabase.spec.deploymentClients; Helm upgrades alone do not upgrade CRDs.

image:
  repository: ghcr.io/shipstream/bloodraven
  tag: "1.3.2"
  pullPolicy: IfNotPresent

replicaCount: 1

# Optional Organization license JWT. Public assertion, not a secret.
# license: "eyJhbGciOiJFZERTQSIsImtpZCI6ImJyLTEiLCJ0eXAiOiJKV1QifQ...."

leaderElection:
  enabled: true

metrics:
  service:
    enabled: true
  serviceMonitor:
    enabled: true
    interval: 30s
    scrapeTimeout: 10s
    labels:
      release: kube-prometheus-stack

grafanaDashboards:
  enabled: true
  namespace: monitoring
  folder: Bloodraven

auxiliary:
  service:
    enabled: false
    wsAllowedOrigins: "https://dashboard.example.com"

Apply:

helm upgrade --install bloodraven bloodraven/bloodraven \
  --namespace bloodraven \
  --create-namespace \
  --values bloodraven-values.yaml

NetworkPolicy recommendations

Allow only these paths:

Post-install verification

kubectl rollout status deployment/bloodraven -n bloodraven
kubectl get crd mysqlfailovergroups.shipstream.io mysqlbackups.shipstream.io mysqlbackupverifications.shipstream.io
kubectl get service -n bloodraven
kubectl auth can-i list mysqlfailovergroups.shipstream.io --as=system:serviceaccount:bloodraven:bloodraven

Before production traffic

• Complete Production Hardening.
• Create per-role credentials with Credentials and TLS.
• Configure Prometheus and Grafana.
• Configure S3 backups or PVC backups.
• If using Dragonfly, configure application Redis clients to use <group>-dragonfly and validate status.dragonfly.phase=Ready.
• Run a planned failover in a staging environment.
